Frequently asked questions
Find answers to many common questions related to Trojan deep cycle lithium-ion, flooded lead acid, AGM, and gel batteries. Find answers to commonly asked questions about Trojan lithium-ion batteries on our lithium-ion FAQ page.
How can I tell if a flooded battery is bad? To determine if the battery in a system is experiencing a problem, disconnect all electrical loads, fully charge the batteries then disconnect all charging sources. Allow each battery in the system to stand on open-circuit for about one hour. Measure the voltage of each battery. If the battery voltage spread exceeds .15 volts for a 6-volt battery, or .22 volts for a 12-volt battery a problem is indicated. Battery voltage alone does not confirm a problem. When the voltage spread indicates a problem, you can confirm the problem by taking electrolyte specific gravity readings using a hydrometer. If the specific gravity readings show a spread greater than .030 (30 points), give the batteries an equalization charge and re-test.
How can a flooded battery’s state of charge be accurately measured? The state of charge of a lead acid battery is most accurately determined by measuring the specific gravity of the electrolyte. This is done with a hydrometer. Battery voltage also indicates the level of charge when measured in an open circuit condition. This should be done with a voltmeter. For an accurate voltage reading, the battery should to rest for at least one hour, to let the voltage stabilize.
How far can I tilt my batteries? For flooded batteries, 22 degrees from vertical is the maximum recommended tilt. AGM and Gel batteries can be operated vertically or horizontally.
Can I reduce my maintenance by not gassing my flooded batteries? You will reduce the frequency of watering, but will cause a condition known as stratification, which means the specific gravity of the electrolyte is light at the top of the battery and heavy at the bottom. This condition results in poor performance and reduced battery life.
What can I use to clean a battery and neutralize the electrolyte? A solution of baking soda and water. Use 1 cup of baking soda for every gallon of water.
What is the specific gravity of a fully charged flooded battery? A hydrometer reading of 1.277 or greater indicates full charge for most Trojan batteries. This value is based upon a specified temperature of 80°F (27°C). For temperature correction values, see the Temperature FAQ section of this page.
What is the correct Specific Gravity (SG) of the Trojan Premium Line? How do I determine the correct Specific Gravity of the Trojan Premium Line battery I already have purchased? Yes, Trojan changed SG values of the Premium Line in March 2012 to avoid confusion over correct SG values for the premium and signature lines of flooded batteries. This change does not have any impact on life cycle performance. Trojan Premium Line batteries manufactured prior to March, 2012 have a nominal SG of 1.260 while those produced after March 2012 have a nominal SG of 1.280.
What does the date code mean on a battery and how do I use it to determine the manufacture date? To determine the date of manufacture, refer to the date code on the negative terminal or on the cover near the negative terminal. It consists of a letter and a number. The letter refers to the month and the number refers to a year. Example: A1 = January 2021, B1 = February 2021, . . . L1 = December 2021. A2 = January 2022, B2 = February 2022, . . . L2 = December 2022, etc.
What are the 20-hour and 100-hour rates? The 100-hour rate is an index used in the battery industry to compare batteries of different types and sizes. The 100-hour rate is the amount of Amp hours (Ahs) the battery will deliver during a 100-hour discharge. The capacity of a battery, in Ahs, is a dynamic number that is dependent on the discharge current. For example, a battery that is discharged at 10Ahs will give you more capacity than a battery that is discharged at 100Ahs. With the 100-hr rate, the battery can deliver more Ahs than with the 20-hr rate because the 100-hr rate uses a much lower discharge current than the 20-hr rate. Both rates are used as baselines in different parts of the world. Both rates, however, will give you the same view of a battery. A higher capacity battery will have higher 5- and 20-hour rates than a battery with lower capacity.
When do I need to perform an equalization charge? Equalizing should be performed when a battery is first purchased (also called a freshening charge) and on a regular basis or as needed. How often your battery will require an equalization charge will vary depending on your application. You will need to monitor your battery voltage and specific gravity to determine when equalization is needed. For example, it is time to equalize if the measured specific gravity (SG) values are below manufacturer’s recommended values after charging (recommended value for Trojan deep cycle batteries is 1.285 +/- .007 at 80º F (27º C)). Equalizing is also required if the SG of any individual cell varies by 30 points or more. Reduced performance can also be an indicator that equalizing is necessary. Equalization should be performed when individual battery voltages in a battery pack range greater than 0.15 volts for 6-volt batteries or 0.30 volts for 12-volt batteries.
Does my deep cycle lead acid battery develop a memory? Lead acid batteries do not develop any type of memory. This means that you do not have to deep discharge or completely discharge a battery before recharging it. For optimum life and performance, we generally recommend a discharge of 20 to 50% of the batteries rated capacity even though the battery is capable of being cycled to 80%.
Can I use battery additives? Trojan Battery, as well as other battery manufacturers, does not recommend adding anything to your batteries other than distilled water. Extensive testing has shown that most of these additives do not work as advertised; in fact, some may do a significant amount of harm. Be aware that adding anything other than water to your batteries will void the warranty.
Do you recommend the use of desulfators? We don’t recommend the use of desulfators or any other external device, as they tend do a significant amount of harm. No external device or chemicals need to be added to our products—only distilled water.
Do you ever add acid to a battery? Under normal operating conditions, you never need to add acid. Only distilled, deionized, or approved water should be added to achieve the recommended levels.
How do I select the right battery for my application? Proper battery selection may require the assistance of a knowledgeable battery sales/service technician. Contact your local Authorized Trojan Dealer or call us at 1-800-423-6569 or 562-236-3000.
What are the differences between a deep cycle battery, a starting battery, and a dual-purpose battery? A deep cycle battery has the ability to be deeply discharged and charged many times during its service life. It is designed specifically for powering electrical equipment for long periods of time. An automotive or starting battery is designed for brief bursts of high current and cannot withstand more than a few deep discharges before failure. This is why you can't start your car if you accidentally leave the lights on more than a few times. For applications where both engine starting and light deep cycling are required, a dual-purpose battery is often used. This type of battery is neither a starting nor a deep cycle battery but rather a compromise between the two that allows it to perform both functions adequately. Only deep cycle batteries should be used in renewable energy applications.
What’s better 24 volt or 48 volt systems? Systems with loads greater than 100 watts continuous will be better served by higher voltages such as 24V and 48V due to the reduced size of wiring required to minimize voltage drop, which impacts overall system cost and ease of installation.
Why do manufacturers use different alloys in their batteries (lead calcium, lead antimony, lead selenium, etc.)? The composition of the plate grid alloy can have a major effect on operating characteristics, such as behavior on float charging and cycle life. Older lead antimony designs have good cycling capability but require frequent water additions, particularly towards the end of life, due to antimony migration between the plates. Cells with lead calcium alloys require far less watering, but tend to have a poor cycle life. Lead selenium alloys are actually low-antimony types with the addition of selenium as a hardening agent. Such alloys promote good cycling capability, while maintaining a constant and fairly low level of water consumption. Many variants on these alloy types are commercially available.
What are common mistakes made by flooded battery owners?
- Undercharging: Continually operating the battery in a partial state of charge, or storing the battery in a discharged state results in the formation of lead sulfate compounds on the plates (called sulfation). Both of these conditions reduce the battery’s performance and may cause premature battery failure. Undercharging will also cause stratification, where the sulfuric acid begins to concentrate at the bottom of the battery and increases the build-up of lead sulfate.
- Overcharging: Continuous charging causes accelerated corrosion of the positive plates, excessive water consumption, and in some cases, damaging temperatures in a lead acid battery.
- Under watering: In flooded batteries, water is lost during the charging process. If the electrolyte level drops below the tops of the plates, irreparable damage may occur. Water levels should be checked and maintained routinely.
- Over-watering: Excessive watering of a battery results in additional dilution of the electrolyte, which leads to reduced battery performance. Additionally, watering the battery before charging may result in electrolyte overflow and unnecessary additional maintenance.
How does temperature affect the performance of my batteries? At higher temperatures (above 80º F (27º C)) battery capacity generally increases, usually at the cost of battery life. Higher temperatures also increase the self-discharge characteristic. Colder temperatures (below 80º F (27º C)) will lower battery capacity and prolong battery life. Cooler temperatures will slow self-discharge. Operating batteries at temperatures at or slightly below 80º F (27º C) will optimize both performance and life.
How do I determine my battery capacity when it is colder/hotter? Battery capacity is basically a linear relationship. A good rule of thumb is that for every 15º F (9º C) above 80º F (27º C), capacity is increased by 10% and for every 15º F (9º C) below 80º F (27º C), capacity is reduced by 10%.
How do I account for temperature when taking my specific gravity readings? Temperature affects specific gravity (SG) readings. As temperature increases, the electrolyte solution expands and as temperature decreases the electrolyte solution contracts. As a result, it is a good practice to temperature correct SG readings.
Trojan recommends that for every ten degrees above 80º F (27º C) add 4 points to the hydrometer reading. And for every ten degrees below 80º F (27º C), subtract 4 points from the hydrometer reading.
- Example: At 90º F (32º C) the hydrometer reads: 1.250 the actual reading: 1.250 + .003 = 1.253.
- Example: At 70º F (21º C) the hydrometer reads: 1.250 the actual reading: 1.250 – .003 = 1.247
How much should I compensate the charge voltage for temperature? Temperature will affect voltage readings. As temperature increases, voltage decreases. Conversely, as temperature decreases, voltage increases.
- For every 1º F below 77º F add 0.0028 volts per cell or for every 1 C below 25º C add 0.005 volts per cell to the charger voltage setting.
- Example: A 12 volt battery at 70º F. The recommended charging voltage at 77º F is 14.8 volts. The adjusted charging voltage is 14.8 + (6 cells * 7 degrees below * 0.0028) = 14.92 volts.
- Example: A 12 volt battery at 21º C. The recommended charging voltage at 25º C is 14.8 volts. The adjusted charging voltage is 14.8 + (6 cells * 4 degrees below * 0.005) = 14.92 volts.
- For every 1º F above 77º F subtract 0.0028 volts per cell or for every 1º C above 25º C subtract 0.005 volts per cell to the charger voltage setting.
- Example: A 12 volt battery at 85º F. The recommended charger voltage at 77º F is 14.8 volts. The adjusted charging voltage is 14.8 – (6 cells * 8 degrees above * 0.0028) = 14.67 volts.
- Example: A 12 volt battery at 29.5º C. The recommended charger voltage at 25º C is 14.8 volts. The adjusted charging voltage is 14.8 – (6 cells * 4.5 degrees above * 0.005) = 14.67 volts.
Is there a maximum temperature for charging my lead acid batteries?
When charging lead acid batteries, the temperature should not exceed 120ºF. At this point the battery should be disconnected from all charging sources and loads and given time to cool before resuming the charge process.
Are lead acid batteries recyclable? Lead acid batteries are 99% recyclable. Lead is the most recycled metal in the world today. All lead purchased by Trojan Battery for grid and small parts casting is recycled. The plastic containers and covers of old batteries are neutralized, reground and used in the manufacture of new battery cases. The electrolyte can be processed for recycled wastewater uses. In some cases, the electrolyte is cleaned and reprocessed and sold as battery grade electrolyte. In other instances, the sulfate content is removed as ammonia sulfate and used in fertilizers. The separators are often used as a fuel source for the recycling process.
Where do I recycle my old batteries? Old batteries may be returned to the battery retailer, automotive service station, a battery manufacturer or other authorized collection centers for recycling. If you are not sure where to take your spent batteries, contact your local Authorized Trojan Dealer for assistance.
What are some common myths associated with batteries?
Adding half a non-buffered aspirin in each cell and then performing a fast charge breaks up sulfation and extends battery life. Aspirin forms ascetic acid which attacks the positive grid and active material.
Storing a battery on concrete will discharge it quicker. When battery cases were made from natural rubber, this was true. Today's battery cases are made of polypropylene or other modern materials that allow a battery to be stored anywhere. A battery’s rate of discharge is affected by its construction, its age, and the ambient temperature. The main issue with storing on concrete is that if the battery leaks, the concrete will be damaged.
Consistent care and maintenance will optimize battery performance and ensure long life. Learn how to care for Trojan batteries.
