J305H-AC 6V Flooded Lead Acid Battery

The J305H-AC 6V Flooded Lead Acid battery enhances the productivity of different applications, such as Floor Cleaning Machines, Aerial Work Platforms, and Recreational Vehicles. The engineering of this battery introduces an advanced paste formulation, which extends battery life and reduces overall maintenance costs.

BAttery Quick Facts
Capacity Minutes

@25 Amps / 781 @75 Amps / 215

Capacity Amp-Hours

5-Hr Rate / 295 Ah 10-Hr Rate / 331 Ah 20-Hr Rate / 360 Ah 100-Hr Rate / 400 Ah

Energy (kWh)


Dimensions inches (mm)

Length / 11.66 (296) Width / 6.94 (176) Height / 14.42 (366)

Weight lbs. (kg)

98 (45)

Operating Temperature

-4°F to 113°F (-20°C to +45°C)

Features & Benefits

  • Maxguard® Advanced Design Separator and Alpha Plus® paste formulation for long life, industry-leading performance and lower overall maintenance costs.
  • Two battery case options:
  • Polyon™ case for exceptional durability in heavy service applications
  • Generic case design for standard applications
  • Heat and corrosion resistant
  • With braided rope handles for easy carrying
  • HydroLink™ single-point watering system available
  • Only 5-15% self-discharge per month
  • 99% recyclable



Automotive Post & Stud Terminal DT
